CUBE Bikes Stereo Hybrid 120 Pro 625

CUBE Bikes Stereo Hybrid 120 Pro 625
$3,439.99
$4,299.99
Color: sagemetallic´n´black
Size: X-Large
Please select options Unavailable

Details

The Stereo Hybrid 120 Pro combines comfortable, ground-hugging suspension with intuitive handling and reliable, fuss-free performance. Bosch’s fourth-generation CX drive unit and a large-capacity battery are matched with Shimano’s legendarily easy-to-use Deore 1×12 gears for simple trail-taming power. We added four-piston hydraulic disc brakes with oversize rotors front and rear, for safe stopping in any conditions. Schwalbe’s grippy 2.6in tyres add extra comfort and control, and RockShox suspension front and rear keeps the rubber side down and rolling. It’s all you need for off-the-beaten-path adventures.

The Stereo Hybrid's sleek frame is full of clever touches to make our popular, Bosch-powered trail explorer better than ever. The Modular Battery System tucks the Bosch battery – up to 750Wh – out of sight, and out of the way of dust and water. Integrated cable routing isn't just neat, it also means there are no cable holes in the head tube. The refined four-bar suspension system keeps you isolated from trail shocks for ride-all-day comfort, and the whole lot is wrapped in our Comfort Geometry – with a stiffness-enhancing Boost 148 rear end and 1.5in head tube – for easy handling, plus SizeSplit makes it simple for every rider to find their perfect match. We even made it simple to add accessories like mudguards, a luggage carrier and a kickstand. It's ready for pretty much anything. Are you?

Geometry

SIZESmallMediumLargeX-Large
Seat tube (mm) 370 420 465 515
Top Tube Horizontal (mm) 578 610 635 660
Seat angle (°) 76° 76° 76° 76°
Head tube angle (°) 66.7° 67° 67° 67°
Chainstays (mm) 466 480 480 480
Head tube (mm) 130 135 145 160
Wheelbase (mm) 1199 1244 1270 1297
BB-Height to Hub (mm) -24 -43 -43 -43
Protrusion height - 80mm 784 791 832
Reach (mm) 434 454 476 497
Stack (mm) 610 647 656 670

Specs

Fork RockShox Recon Silver RL Air, Tapered, 15x110mm, eMTB Approved, 130mm, Lockout
Motor Specs Performance CX G4
Battery Type/Weight Bosch PowerTube 626
Charger Type Bosch 4A
Saddle Natural Fit Sequence
Handlebars Newmen Evolution SL 318.25, 760mm
Pedals ACID PP MTB
Cassette Sunrace CSMZ600, 11-51T
Color(s) sagemetallic´n´black
Stem CUBE Performance Stem E-MTB, 31.8mm
Headset ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
Grips ACID Hybrid Perform
Rear Derailleur Shimano Deore RD-M6100-SGS, ShadowPlus, 12-Speed
Shifters Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
Crankset ACID E-Crank, 38T, 170mm
Rims Rodi Tryp 30, 32H, Disc, Tubeless Ready
Front Hub CUBE Engineered By Newmen, 15mm, Boost, Centerlock
Rear Hub CUBE Engineered By Newmen, 12mm, Boost, Centerlock
Seat Post CUBE Performance Post, 30.9mm
Chain Shimano CN-M6101

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
sagemetallic´n´black / X-Large 4054571418173 69527022 CUB491038L
