Details
Have your Touring Hybrid the way you want it. Classic Men's, Trapeze, or Easy Entry - each version features the same attention to detail. Built around Bosch's powerful third-generation motor and PowerTube battery, we've taken care to keep the centre of gravity low for safety and easy handling. Efficient Comfort Geometry does exactly what it says, putting you in the ideal position to enjoy every ride. And the Integrated Carrier is a masterpiece of understated engineering excellence, providing a strong and rigid means of carrying your day-to-day possessions with you.
The beauty of a great bicycle is its versatility - and few bikes are more versatile than the Touring Hybrid Pro. Shimano's wide-ranging 11-speed Deore gears work seamlessly with Bosch's powerful Generation 3 motor and PowerTube battery to get you where you need to be. There's our strong, rigid Integrated Carrier for your essential bits and pieces, powerful Shimano hydraulic disc brakes for all-weather stopping, and full-length mudguards to help keep you dry. We even fitted an integrated lighting system and a kickstand. And an adjustable stem, suspension seatpost and 100mm suspension fork with big-volume, grippy tires all help deliver you to your destination in comfort.
Trapeze 46 cm / X-Small | Trapeze 50 cm / Small | Trapeze 54 cm / Medium | |
---|---|---|---|
A. Reach (mm) | 392.6 | 404.4 | 406.6 |
B. Stack (mm) | 626.5 | 626.5 | 654.6 |
C. Standover (mm) | 796.4 | 885.8 | 780.3 |
D. Effective Top Tube (mm) | 584 | 595 | 606 |
E. Head Tube Angle (deg) | 69.5 | 69.5 | 69.5 |
F. Head Tube Length (mm) | 105 | 105 | 135 |
G. Seat Tube Angle (deg) | 73 | 73 | 73 |
H. Seat Tube Length (mm) | 440 | 480 | 520 |
J. Bottom Bracket Drop (mm) | 67.5 | 67.5 | 67.5 |
M. Wheelbase (mm) | 1139.9 | 1150.9 | 1163.6 |
O. Chainstay Length (mm) | 488 | 488 | 488 |
Specs
Frame | Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Tapered Headtube, Full Integrated Battery, Integrated Carrier 2.0 |
---|---|
Fork | SR Suntour NVX30 Coil, 100mm |
Rims | CUBE EX23, 36H, Disc, Tubeless Ready |
Tires | Schwalbe Big Ben, Performance, K-Guard, 55-622 |
Crankset | ACID E-Crank, 40T, 175mm (EE: 170mm) |
Shifters | Shimano Deore SL-M5100, Rapidfire-Plus |
Rear Derailleur | Shimano Deore RD-M5100-SGS, 11-Speed |
Cassette/Freewheel | Shimano Deore CS-M5100, 11-51T |
Chain | KMC X11 |
Brakes | Shimano BR-MT200, Hydr. Disc Brake (180/180) |
Handlebars | CUBE Comfort Trail Bar, 700mm |
Tape/Grips | Natural Fit Comfort |
Stem | CUBE Comfort Stem Pro, 31.8mm, Adjustable |
Headset |
M/Z: ACROS AZF-1039, 1 1/8" straight, Top Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) EE: ACROS AZX-1041, BlockLock 135°, 1 1/8" straight, Top Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) |
Seatpost | CUBE Suspension Seatpost HD, 30.9mm |
Saddle | Natural Fit Sequence Comfort |
Pedals | ACID PP Trekking |
Accessories & Extras |
FRONT LIGHT CUBE Shiny 50 Lux, 12V, DC REAR LIGHT ACID Mudguard Rear Light PRO-E, 12V, DC KICKSTAND CUBEstand Cmpt MUDGUARDS ACID 65 BB-Mount BELL Easy Bell CARRIER CUBE Integrated Carrier 2.0, ACID RILink Adapter Compatible, SnapIt Compatible |
Motor | Bosch Drive Unit Performance Generation 3 (65Nm) Cruise (250Watt) |
Battery | Bosch PowerTube 500 |
Controller/Display | Bosch Intuvia |
Charger | Bosch 2A |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
lunar'n'grey / 50cm | 04054571382863 | 59517050 cm/S | 20242244507S |
lunar'n'grey / 54cm | 04054571382870 | 59517054cm/M | 20242701305M |
lunar'n'grey / 58cm | 04054571382887 | 59517058cm/L | 20242621572L |
lunar'n'grey / 62cm | 04054571382894 | 59517062 cm/XL |
